GPR-R12
Red Beam
H/V Leveling Rotary Laser
◎ Eletronic Tilt Sensor Leveling System
◎ Auto H leveling mode, Auto V leveling mode, Manual Grade mode
◎ 3 Dots works at the same time (Up / Down / Horizontal)
◎ 3 kinds status for laser beam control (Rotation / Scan / Dot)
◎ ADS Mode Alarm Design
◎ IP66 protection with Rubber housing
| Model | GPR-R12 |
| Laser Beam | 635nm Red Beam |
| Accuracy | ±20" |
| Leveling Range | ±5° |
| Rotation Speed Range | 0/60/120/300/600 r.p.m |
| Laser Beam Scan Range | 0°/10°/45°/90°/180° |
| Working Range | Dia. 600m (W/Detector) |
| Working Temperature | -10℃~+40℃ |
| Power Supply | 4 x C Batteries / 4 x Ni-MH Batteries |
| IP Grade | IP-66 |
| Size | 165(L)x165(W)x205(H)mm |
| Weight | 2.6kg（with Batery） |
